Products Detail
|
Specifications |
CJY10/6GP |
CJY10/7GP |
|
|
Adhesive Total Weight (t) |
10 |
10 |
10 |
|
Track Gauge (mm) |
600 |
762 |
900 |
|
Wheelbase (mm) |
1100 |
1100 |
1100 |
|
Wheel Diameter Over Tread |
680 |
680 |
680 |
|
Coupler Height over Steel Rail(mm) |
320/430 |
320/430 |
320/430 |
|
Min Curve radius (m) |
7 |
7 |
7 |
|
Pantograph Operation Height (mm) |
1800-2200 |
1800-2200 |
1800-2200 |
|
Braking Method |
Mechanical&Electrical |
Mechanical&Electrical |
Mechanical&Electrical |
|
Max Tractive Effort (KN) |
27.5 |
27.5 |
27.5 |
|
Max Speed (km/h) |
20 |
20 |
20 |
|
Rated Speed (km/h) |
10 |
10 |
10 |
|
Power of Traction (kw) |
2*22(30) |
2*22(30) |
2*22(30) |
|
DC Input Power Voltage |
DC250/550 |
DC250/550 |
DC250/550 |
|
Transmission |
Single Level Spur Gearing |
Single Level Spur Gearing |
Single Level Spur Gearing |
|
Controller |
AC Frquency Conversion |
AC Frquency Conversion |
AC Frquency Conversion |
|
Over all Dimensions (mm) |
4460*1060*1590 |
4460*1340*1590 |
4460*1340*1590 |
|
Service & Application |
Mucking in Mining&Tunneling |
Mucking in Mining&Tunneling |
Mucking in Mining&Tunneling |
