Products Detail
|
Specification |
Rail Height (mm) |
Bottom Width (mm) |
Head Width (mm) |
Web Thickness (mm) |
Length (m) |
Theoretical Weight (kg/m) |
Grade |
|
8kg |
65 |
54 |
25 |
7 |
6 |
8.42 |
55Q Q235 50Q |
|
12kg |
69.85 |
69.85 |
38.1 |
7.54 |
6 |
12.2 |
|
|
15kg |
79.37 |
79.37 |
42.86 |
8.33 |
6-9 |
15.2 |
|
|
18kg |
90 |
80 |
40 |
10.0 |
6-9 |
18.06 |
|
|
22kg |
93.66 |
93.66 |
50.80 |
10.72 |
6-10 |
22.3 |
|
|
24kg |
107 |
92 |
51 |
10.9 |
6-10 |
24.46 |
|
|
30kg |
107.95 |
107.95 |
60.33 |
12.30 |
7-10 |
30.1 |
|
|
38kg |
134 |
114 |
68 |
13 |
12.5 |
38.733 |
45Mn |
|
43kg |
140 |
114 |
70 |
14.5 |
12.5 |
44.653 |
|
|
50kg |
152 |
132 |
70 |
15.5 |
12.5 |
51.514 |
|
|
60kg |
176 |
150 |
73 |
16.5 |
12.5 |
60.64 |
|
|
70kg |
120 |
120 |
70 |
28 |
12 |
52.80 |
45Mn 50Mn u71Mn u71MnX U75vx |
|
80kg |
130 |
130 |
80 |
32 |
9-12 |
63.69 |
|
|
100kg |
150 |
150 |
100 |
38 |
9-12 |
88.96 |
|
|
120kg |
170 |
170 |
120 |
44 |
9-12 |
118.1 |
