Products Detail
|
Brand: China Coal |
|
|
Model No. : MO-850-400w |
|
|
Solar Panel and Solar Battery |
|
|
Solar panel |
4×300W Monocrystalline silicon Solar Panels |
|
Solar battery |
4×150A colloid battery (free maintenance) |
|
charger |
50A |
|
Performance Description |
|
|
DC voltage |
DC24V , with AC inverter |
|
AC output |
220V, 50Hz |
|
Temperature range |
-32°~﹢42° |
|
Switch control mode |
Setting time control |
|
Lamp |
|
|
Type of lamp |
LED |
|
Lamp quantity |
4 units |
|
Lamp power |
4*100W |
|
Lamp lumen |
125LM/W |
|
The environment temperature |
-36~60℃ |
|
Waterproof level |
IP65 |
|
luminosity |
15.000 lumens per fixture;60.000 total lumens |
|
Lamp angle |
125°-135° |
|
Color |
White（4500K-5500K） |
|
Lamp Working Time |
12-16h |
|
Control Box |
|
|
Solar charge controller |
Control the solar power system and protect the battery |
|
Remote control |
Control the light by remote controller or manually |
|
Other electrical system |
Supply power to other electrical equipment within the power range |
|
Trailer and Pole |
|
|
Tire |
Two 560mm car tires |
|
Mast height |
7M （Can be customized any height） |
|
Lifting the way |
Manual operation |
|
Dimension (Adjustable) |
|
|
L×W×H (Travel ) |
2480×2150×1820(mm) |
|
L×W×H (working) |
3480×4800×7000(mm) |
|
CBM |
|
|
20 ft Container |
6 Sets |
|
40 ft Container |
12 Sets |
|
Weight |
|
|
Net weight |
880KG |
|
Gross weight |
930KG |
|
Main Parts Life Time |
|
|
Solar panel |
25 Years |
|
Solar battery |
6 Years |
|
LED light |
6 Years |
|
Others |
|
|
Windproof ability |
8 Degree |
|
Protection level |
IP65 |
|
Optional Parts |
|
|
Pneumatic mast |
4M/6M/8M |
|
Bump brake |
Standard |
|
Tire |
560mm |
